FEATURES:
- No tools required—connect and disconnect without tools for easy and flexible installation.
- Locking clip—for extra connection security.
- NO flow restriction—no pipe stiffeners for copper and CPVC pipes allows for full flow without additional head losses.
- Rotate under pressure—for Brass, Mini, and Plastic fittings.
- Zero-leak patented O-ring guide for Plastic Series—protects the O-ring from damage during connection, helps align the tubing with the O-ring every time, and prevents the O-ring from becoming dislodged.
| PART # | SIZE CTS X NPT | BAG QTY |
| 8S 3501-0806 | 3/8” X 3/8” | 5 |
| 8S 3501-0808 | 3/8” X 1/2” | 5 |
| 8S 3501-1006 | 1/2” X 3/8” | 5 |
| 8S 3501-1008 | 1/2” X 1/2 ” | 5 |
| 8S 3501-1012 | 1/2” X 3/4” | 5 |
| 8S 3501-1014 | 1/2” X 3/4” (MGHT) | 5 |
| 8S 3501-1412 | 3/4” X 3/4” | 5 |
- Base Unit:
- EA
