PART ME - MALE FIXED ELBOW - NPTF THREAD - WHITE POLY
Members Only Pricing - Login or Signup for Your Special Rates
The PP Range of inch-size push-in
fittings is offered for tube sizes 1/4” O.D. to 1/2” O.D. The fittings
are manufactured in white polypropylene with food grade EPDM O-rings.
They have been developed to satisfy the filtered pure water market and
wide range of applications.
The PPM Range is NOT suitable for
compressed air applications.
WORKING PRESSURES AND
TEMPERATURES:
- Max. 150 psi at 70˚F (Max.
10 Bar at 20˚C)
- Max. 60 psi at 140˚F (Max. 4 Bar at 60˚C)
- Min. 33˚F/1˚C
| PART # | JG PART # | TUBE O.D. | THREAD NPTF | BAG QTY |
| 8J ME140180WP | PP480821W | 1/4” | 1/8” | 10 |
| 8J ME140140WP | PP480822W | 1/4” | 1/4” | 10 |
| 8J ME140380WP | PP480823W | 1/4” | 3/8” | 10 |
| 8J ME380140WP | PP481222W | 3/8” | 1/4” | 10 |
| 8J ME380380WP | PP481223W | 3/8” | 3/8” | 10 |
| 8J ME120380WP | PP481623W | 1/2” | 3/8” | 10 |
- Base Unit:
- EA
