PART UTCR - UNION TEE REDUCING CONNECTOR - WHITE POLY
Members Only Pricing - Login or Signup for Your Special Rates
The PP Range of inch-size push-in
fittings is offered for tube sizes 1/4” O.D. to 1/2” O.D. The fittings
are manufactured in white polypropylene with food grade EPDM O-rings.
They have been developed to satisfy the filtered pure water market and
wide range of applications.
The PPM Range is NOT suitable for
compressed air applications.
WORKING PRESSURES AND
TEMPERATURES:
- Max. 150 psi at 70˚F (Max.
10 Bar at 20˚C)
- Max. 60 psi at 140˚F (Max. 4 Bar at 60˚C)
- Min. 33˚F/1˚C
| PART # | JG PART # | TUBE O.D. END | TUBE O.D. END | TUBE O.D. BRANCH | BAG QTY |
| 8J UTCR140140380WP | PP30080812W | 1/4” | 1/4” | 3/8” | 10 |
| 8J UTCR380140WP | PP30121208W | 3/8” | 1/4” | 3/8” | 10 |
| 8J UTCR381438WP | PP30120812W | 3/8” | 3/8” | 1/4” | 10 |
| 8J UTCR120380WP | PP301612W | 1/2” | 1/2” | 3/8” | 10 |
- Base Unit:
- EA
