Plastic Check Valves: Series 426 - PUSH-CONNECT X MALE

Plastic Check Valves: Series 426 - PUSH-CONNECT X MALE

SKU:
6S426CM
Members Only Pricing - for Your Special Rates
Current Stock:
Sign In
Description

FEATURES, APPLICATIONS AND/OR NOTES:

  • The 426 series PVC valve operates in any position, horizontal or vertical, and is available in mix or matched end combination.
  • Standard cracking pressure 1 psi (optional 1/3, 3 or 7 psi available) with a maximum operating pressure of 125 psi and a maximum operating temperature of 140° F.
  • Buna seals standard, ethylene propylene or fluoroelastomer seals available.
  • Guided stainless steel or teflon ball with O-Quad ring seat. Available with hastelloy springs.
  • For technical assistance, custom springs, and end combinations, please call.
  • NSF LISTED COMPONENT


PART #
6S PVC-426-4C2M
6S PVC-426-4C4M
Additional Information
Base Unit:
EA
