Type 103D | Steel Case, Dry - Center-Back Mount w/ U-Clamp

Type 103D | Steel Case, Dry - Center-Back Mount w/ U-Clamp

SKU:
9P103D
Members Only Pricing - for Your Special Rates
Current Stock:
Sign In
Description

FEATURES:

  • Steel Case, Chrome Bezel, Plastic Lens
  • Brass Tube and Socket, Center-Back Mount w/ U-Clamp


CONNECTION SIZES:

  • 1/8” Thread Size on 1-1/2” Dial Size
  • 1/8” and 1/4” Thread Sizes on 2” Dial Size
  • 1/4” Thread Size on 2-1/2”and 3-1/2” Dial Sizes


NOTE:

Due to the ongoing import tariffs, a 11.25% surcharge will be applied to all orders, effective 9/4/2019 until further notice.


PressuresDial Size
1/8" Thread Size1/4" Thread Size
1-1/2"2"2"2-1/2"3-1/2"
A = 30/0" hg VAC9P103D-158A 9P103D-208A 9P103D-204A 9P103D-254A 9P103D-354A
CB = 30/0/15 PSI9P103D-158CB 9P103D-208CB 9P103D-204CB 9P103D-254CB 9P103D-354CB
CC = 30/0/30 PSI9P103D-158CC 9P103D-208CC 9P103D-204CC 9P103D-254CC 9P103D-354CC
CD = 30/0/60 PSI9P103D-158CD 9P103D-208CD 9P103D-204CD 9P103D-254CD 9P103D-354CD
CE = 30/0/100 PSI9P103D-158CE 9P103D-208CE 9P103D-204CE 9P103D-254CE 9P103D-354CE
CF = 30/0/150 PSI9P103D-158CF 9P103D-208CF 9P103D-204CF 9P103D-254CF 9P103D-354CF
CG = 30/0/200 PSI9P103D-158CG 9P103D-208CG 9P103D-204CG 9P103D-254CG 9P103D-354CG
CH = 30/0/300 PSI9P103D-158CH 9P103D-208CH 9P103D-204CH 9P103D-254CH 9P103D-354CH
B = 0/15 PSI9P103D-158B 9P103D-208B 9P103D-204B 9P103D-254B 9P103D-354B
C = 0/30 PSI9P103D-158C 9P103D-208C 9P103D-204C 9P103D-254C 9P103D-354C
D = 0/60 PSI9P103D-158D 9P103D-208D 9P103D-204D 9P103D-254D 9P103D-354D
E = 0/100 PSI9P103D-158E 9P103D-208E 9P103D-204E 9P103D-254E 9P103D-354E
F = 0/160 PSI9P103D-158F 9P103D-208F 9P103D-204F 9P103D-254F 9P103D-354F
G = 0/200 PSI9P103D-158G 9P103D-208G 9P103D-204G 9P103D-254G 9P103D-354G
H = 0/300 PSI9P103D-158H 9P103D-208H 9P103D-204H 9P103D-254H 9P103D-354H
I = 0/400 PSI---9P103D-254I 9P103D-354I
J = 0/500 PSI---9P103D-254J 9P103D-354J
K = 0/600 PSI---9P103D-254K 9P103D-354K
L = 0/800 PSI---9P103D-254L 9P103D-354L
M = 0/1000 PSI---9P103D-254M 9P103D-354M
N = 0/1500 PSI---9P103D-254N 9P103D-354N
O = 0/2000 PSI---9P103D-254O 9P103D-354O
P = 0/3000 PSI---9P103D-254P 9P103D-354P
Q = 0/4000 PSI---9P103D-254Q 9P103D-354Q
R = 0/5000 PSI---9P103D-254R 9P103D-354R
S = 0/6000 PSI---9P103D-254S 9P103D-354S
Additional Information
Base Unit:
EA
