Style 5015 - Clear Braided All Purpose PVC Hose - Food Grade
Members Only Pricing - Login or Signup for Your Special Rates
FEATURES:
- Compounds used made from materials on the FDA approved list
- Clear PVC Tube, Polyester Reinforced, Clear PVC Cover
- Lightweight, Non-Marking & Flexible
- NSF Certified under Standard NSF-61
- 4:1 Tested Safety Factor on Burst PSI
APPLICATIONS:
- Air, Water & Food Transfer
- Light Vacuum Lines
- Wire Conduit
TEMPERATURE RANGE:
+25°F to +150°F
BRANDING:
SPECIALTY SALES STYLE 5015 (DATE CODE) CANADA
NOTE:
Cut lengths available - 15% surcharge.
|
PART # |
I.D. |
O.D. |
WORKING PRESSURE AT 68° F |
WEIGHT / 100’ |
LENGTH |
|
2H 5015/0187 |
3/16” |
0.370” |
250 PSI |
4.5 LBS |
300’ COIL |
|
2 H5015/025 |
1/4” |
0.455” |
250 PSI |
6.5 LBS |
300’ COIL |
|
2H 5015/0312 |
5/16” |
0.515” |
250 PSI |
7.5 LBS |
300’ COIL |
|
2H 5015/0375 |
3/8” |
0.595” |
225 PSI |
9 LBS |
300’ COIL |
|
2H 5015/050 |
1/2” |
0.745” |
200 PSI |
14.5 LBS |
300’ COIL |
|
2H 5015/050-500 |
1/2” |
0.745” |
200 PSI |
14.5 LBS |
500’ REEL |
|
2H 5015/0625 |
5/8” |
0.745” |
200 PSI |
16.5 LBS |
300’ COIL |
|
2H 5015/075 |
3/4” |
1.020” |
150 PSI |
23 LBS |
300’ COIL |
|
2H 5015/075-100 |
3/4” |
1.020” |
150 PSI |
23 LBS |
100’ COIL |
|
2H 5015/075-500 |
3/4” |
1.020” |
150 PSI |
23 LBS |
500’ REEL |
|
2H 5015/100 |
1” |
1.290” |
125 PSI |
32 LBS |
200’ COIL |
|
2H 5015/100-100 |
1” |
1.290” |
125 PSI |
32 LBS |
100’ COIL |
|
2H 5015/100-500 |
1” |
1.290” |
125 PSI |
32 LBS |
500’ REEL |
|
2H 5015/125 |
1-1/4” |
1.625” |
100 PSI |
58 LBS |
100’ COIL |
|
2H 5015/150 |
1-1/2” |
1.925” |
100 PSI |
69 LBS |
100’ COIL |
|
2H 5015/200 |
2” |
2.480” |
75 PSI |
100 LBS |
100’ COIL |
- Base Unit:
- FT
