Style 5016 - Clear Braided PVC General Purpose Hose
Members Only Pricing - Login or Signup for Your Special Rates
FEATURES:
- Clear PVC Tube and Cover with Polyester Reinforcement
- Lightweight and Flexible
- 80 Durometer
- Blue & Red Spiral Polyester Tracers
- 4:1 Tested Safety Factor on Burst PSI
APPLICATIONS:
- Air, Water & Light Solids Transfer
- Light Vacuum Lines
- Wire Conduit
TEMPERATURE RANGE:
+25°F to +150°F
BRANDING:
SSI STYLE 5016 (DATE CODE) CANADA
PART # |
I.D. |
O.D. |
WORKING PRESSURE AT 68° F |
WEIGHT / 100’ |
LENGTH |
2H 5016/025 |
1/4” |
0.440” |
200 PSI |
5 LBS |
300’ COIL |
2H 5016/0375 |
3/8” |
0.595” |
200 PSI |
9 LBS |
300’ COIL |
2H 5016/0375-500 |
3/8” |
0.595” |
200 PSI |
9 LBS |
500’ REEL |
2H 5016/050 |
1/2” |
0.720” |
200 PSI |
12 LBS |
300’ COIL |
2H 5016/050-400 |
1/2” |
0.720” |
200 PSI |
12 LBS |
400’ COIL |
2H 5016/050-500 |
1/2” |
0.720” |
200 PSI |
12 LBS |
500’ REEL |
2H 5016/0625 |
5/8” |
0.845” |
175 PSI |
16 LBS |
300’ COIL |
2H 5016/075 |
3/4” |
0.970” |
200 PSI |
18 LBS |
300’ COIL |
2H 5016/100 |
1” |
1.280” |
115 PSI |
22 LBS |
200’ COIL |
2H 5016/100-100 |
1” |
1.280” |
115 PSI |
22 LBS |
100’ COIL |
2H 5016/125 |
1-1/4” |
1.625” |
110 PSI |
46.5 LBS |
100’ COIL |
2H 5016/150 |
1-1/2” |
1.925” |
110 PSI |
62 LBS |
100’ COIL |
- Base Unit:
- FT
